5 Litre Ribbon Blender
Progress photos of a 5 litre ribbon blender with full vacuum rating as well as a heating jacket complete with thermostat controlled heating elements all set up to be on castors for a mobile solution.
Steam Injected Rotating Cooker
Just completed another steam injected rotating cooker for a food application for a multinational food company.
32 Litre Dosing Tank
The pharma customer needed a magnetic drive mixer to be installed in their small 32 litre dosing tank.
6 Compartment Coffee Bean Hopper
While we are pretty proud of this 6 compartment coffee bean hopper, its not only about the fabrication, but also the installation knowledge and skills developed over many years.
Special Shaped Rectangular Tank
A customer needed a special shaped rectangular tank for a specific requirement.
Tank Replacement
A multinational chemical company needed a replacement tank, so details had to be closed so as to lift out and lift in the new one - the pipework connections on the new tank matched the old chemical.
6000 Litre Boiler Feedwater Tank
This tank is to replace an existing tank, which will be lifted in through the roof and therefore the ladder and platform need to be easily removeable and reinstalled.
316 Grade 500 Litre Jacketed Pressure
STOCK 316 grade 500 LITRE JACKETED PRESSURE/VACUUM CONTRAMIX TANK
Heating Station Mix Tank
Just finished a very neat mix station with jacketed [for heating] mix tank.
Pre-polishing Pressure Vessel
In house pre-polishing of a pressure vessel and then being plastic covered to protect the surface while fabricating.
20 Litre and 10 Litre Concrete Mixer
Both mixers have a spare bowl, so one can be getting washed while the other is operating. The bowls are easily removed and replaced with a simple clamp at the back.
Tank Vulnerable to Substantial Accidental Damage
We had an urgent call out this week to fix a leaking 250,000 litre silo. Now a food grade silo this big is an expensive bit of equipment, but unfortunately they are simply and easily catastrophically damaged.
25,000 Litre Heated Tank
A 25,000 litre heated, insulated & clad and agitated storage tank, heated with heat trace ready to be transported to site.
4 off Mobile Vacuum Transfer Vessels
24 off mobile pressure / vacuum transfer vessels for the food industry.
2000 litre ribbon blender
A 2000-liter ribbon blender is still going strong, the only maintenance it has probably had changes to the gland packing on the shaft seals.
Jacketed Contra-Mix Tanks Fabricated from SAF2205
2 off jacketed contra-mix tanks fabricated from SAF2205 - a duplex stainless steel for a corrosive environment and fitted to a full stainless steel platform
Large Stainless Steel Platform (under construction)
These photos are of 1/2 a platform under construction. All chequer plate flooring is fully sealed welded and folded at the edges to create a very clean arrangement.
ETFE Lined Vessel for Chemical Recovery
Australian-made custom stainless steel solutions got a small ETFE-lined vessel for chemical recovery at a demonstration facility.
Stainless Steel Transition Hoppers
Just another day in the office - some 3mm transition hoppers with sight glasses, specific baffle and nozzles
200 Litre Blender – Stingray Range
Our recent development of a 200 litre blender to add to our stingray range
Standard Stainless Tank
While there may be common sizes, very often those sizes don't work because of site constraints, whether it be the width or the height, or the clearance under the tank.
Food Grade Mobile Pressure Vacuum Vessels
24 off mobile pressure/vacuum for transporting/storing/dispensing viscous semi-liquid food products in the process of being built for a reputable Australian Food manufacturer.
Shear Mixing Head Repaired
The customers shear mixing head had been repaired/refurbished a number of times until finally needed replacing. Contact us for a bespoke system to suit your specific needs
Full Stainless Steel Mobile Laboratory Bench
This laboratory bench includes 2 off lexan faced PC monitor locations.
3000 Litre Steam Jacketed Mixing Tank Viscous Sugar Based Product
Just finished this mixing tank which is insulated and clad with seal welded cladding, having a scrape surface cage type mixer and CIP spray ball setup. All are built to exacting GMP and safety standards.
4 Off 5000 Litre Open Top Specialty Water Tanks
Nothing special about these tanks except the customer who is using these tanks as part of a larger project commented.
Another Set of Pharma Grade Mix Tanks
The 50 litre tank has a heat trace system fitted for heating the tank - completely enclosed in a seal welded jacket and a tidy junction box.
Stingray CM200 – Just Completed and Additional Size to our Range
This tumble type blender [best described as a concrete mixer, except this it isn't for concrete, but rather for food and similar products] has a working capacity of 200 litres / 200 kgs.
90 Litre Vats for Processing
Nothing very exciting, but you can be sure these vats will be still operational after 100 years.
Custom Large Diameter Duct Work
Large ductwork needs the right design, material, gauge, adaptors, and fittings to perform well in industrial and large manufacturing environments.
6 Off Full Stainless Food Grade 2000 Litre Capacity IBCs
IBC's [Intermediate Bulk Containers] play an important part in increasing efficiency in the production facility.
75 Litre Ex Rated Pharma Grade Mobile Mix Tank
A very tidy mobile EX-rated mix tank complete with load cells for batching as well as dispensing with accuracy.
250 Litre All Stainless Paddle Blender and Platform
This blender was built after conducting tests in our pilot scale blender to determine the best method of mixing the customers ingredients.
When Repairs Just Don’t Cut It Anymore
Had to pay a site visit this week to suggest what could be done for this bag filter vessel.
1 off 100 Litre Mix Tank and 2 off 100 Litre Holding Tanks
A rush job to help out a valued customer delivered in the promised timeframe.
100 Litre Vacuum Rated Ribbon Blender For a Lab Application
A customer required a lab blender to blender to do product trials in their lab with details to be scaled down from their production equipment.
Australian Made Custom Stainless Steel Fabrication
Not really sure what is it! But it looks good! All were built from scratch in our Minto workshop.
Mixing Characteristics of the Ribbon Blender
Focusing on the production of Ribbon blenders for the months of May and June 2022
1300 Litre Forkliftable Storage Tanks
High polished storage tanks to make it easier for the customer's product to be cleaned off.
Another 2000 Litre Ribbon Blender
Not the greatest photos, but another quality ribbon blender complete with: * associated platform, * painted support structure - made separate so as to be able to install the blender inside an existing room * included is a vacuum lifting system for the operator to load the mixer with bags * 3 alternative size screens complete with safety switch tongue * upper and lower level controls for ease of operating.
Customised Mix Stations Specifically for Pre-Blending
Our mix stations are a highly flexible piece of equipment especially when speeding up the process of pre-blending that includes blending powder into liquid.
A Very Neat Collection of Mix Tanks for a High-End Cosmetics Company
All mobile units to provide a very flexible setup. From a heated cage mixer with scrapers and recirculation through an emulsifier to a heated general mix tank and a mobile storage tank.
